Excavator Stump Planer Package Deal – Excavators up to 10 tons (22,000lbs)

The ultimate excavator stump planer setup for excavators up to 6 tons!

3300-30 or 6000-40 Auger Drive for Excavators up to 10 tons
Double Pin Cradle Hitch (built to machine spec – usual lead time is 2-3 weeks)
10″ or 14″ Stump Planer Auger Attachment
Hoses and Quick Release Flat Face Couplers

Available now!

Price range: $4,350.00 through $6,475.00

Drive Model

Stump Planer Diameter

Clear

Sale!

auger drive excavator double pin cradle mount

auger torque stump planer grinding stumps

Share On Social Media

The Ultimate Excavator Stump Planer Auger Package Deal for machines up to 10 tons!

This package deal comes with your choice of hydraulic drive, double pin cradle mount to suit your excavator, hoses & couplers and choice of 10″ or 14″ stump planer auger bit!

Our Excavator Stump Planer package gives you the best deal on the market for a stump grinder setup! If you have a special attachment inquiry or are unsure of your machine’s compatibility with a particular attachment, please do not hesitate to contact us on (941) 212-0037.

Other attachments are also available to work with this auger setup like log splitters & auger bits.

Removal of tree stumps is a noisy, messy and time consuming job. Traditionally removal meant showering chippings over a wide area and making clean up a time-consuming exercise. The Auger Torque Stump Planer is the quick and easy additional attachment to any earth drill for the effective, easy and clean removal of tree stumps. A must-have product for those working in ground preparation and woodland maintenance.

Specifications

Model 3300-30 (up to 6 tons or 30GPM)

Mini Excavators up to 12,000lbs (6 Ton)

Suits S4 AUGERS (2″ Hex)

Torque Range: 1,106 – 3,318 ft-lb
Oil Pressure Range: 1,160 – 3,481 psi
Output Shaft: 2″ Hex (US Standard)

Oil Flow Range: 15 – 30GPM
Speed Range: 42 – 97 RPM

Unit Height: 26 in.
Unit Diameter: 10 in.
Unit Weight: 166lbs – 277lbs w/ excavator mount

Hitch Options: Double Pin Cradle (recommended)

Double Pin Hitches are built to suit the machine’s pin dimensions. These can be manually pinned to the machine or picked up by a coupler.

We also can build machine specific “quick connect” mounts for Kubota, John Deere, Bobcat etc. These are to suit the specific machine make & model.

Package Deal includes the following:

3300-30 Auger Drive for Excavators with Double Pin Cradle Hitch, 10″ Stump Planer Attachment, Hoses and Quick Release Flat Face Couplers

Double Pin Cradle Hitch will be built to machines exact specifications: Pin Diameter, Stick Width & Pin Centers required[

Suitable Excavators for this 3300-30 package (as a guideline):

Bobcat E35, E42
CASE CX30, 37
CAT 303, 304, 305
JCB 8035
JCB 45Z, 48Z
John Deere 35G, 50G
Komatsu PC35, 55
Kubota KX037, KX042
Kubota U35, U50
Sany SY35, 50
Takeuchi TB240, 250
Volvo ECR40, 50, 55
Yanmar ViO35, 55

Model 6000-40 (up to 10 tons or 40GPM)

Excavators up to 22,000lbs (10 Ton)

Sutis S5 AUGERS (2.5″ Hex)

Torque Range: 2,004 – 6,012 ft-lb
Oil Pressure Range: 1,160 – 3,481 psi
Output Shaft: 2.5″ Hex

Oil Flow Range: 19 – 40 gpm
Speed Range: 33 – 70 rpm

Unit Height: 31 in.
Unit Diameter: 11 in.
Unit Weight: 260 lbs not including excavator mount

Hitch Options: Double Pin Cradle (recommended)

Double Pin Hitches are built to suit the machine’s pin dimensions. These can be manually pinned to the machine or picked up by a coupler.

We also can build machine specific “quick connect” mounts for Kubota, John Deere, Bobcat etc. These are to suit the specific machine make & model.

Package Deal includes the following:

6000-40 Auger Drive for Excavators with Double Pin Cradle Hitch, 10 or 14″ Stump Planer Auger Attachment, Hoses and Quick Release Flat Face Couplers

Double Pin Cradle Hitch will be built to machines exact specifications: Pin Diameter, Stick Width & Pin Centers required

Suitable Excavators for this 6000-40 package (as a guideline):

Bobcat E60, E88
CASE CX50, 80
CAT 305, 308
JCB 55z, 85z
John Deere 50G, 85G
Komatsu PC55, PC88
Kubota KX057
Kubota U50, U55
Sany SY50, 80
Takeuchi TB175, 260, 280
Volvo ECR55, 88
Yanmar ViO55, 80

Auger Drive Features

Forged Hood Ears

Auger drives take up a lot of stress in certain areas, especially the hood and ears on top of the unit. These are forged pieces to endure the strain of drilling. Hood pins are also locked into place to ensure they never detach from the auger drive.

Hoses & Coupler Options

All of our 2” hex come with high quality 1/2″ hoses and couplers included.
Larger auger drive units come with hoses to match the motor size of the unit.
6000-40 (2.5” hex) drive come with ¾” hoses
11000-45 to 18500-45 (3” square) drives come with 1” hoses.

Non Dislodgement Shaft

One unique feature of the auger torque range is the non-dislodgement shaft. The gearbox design of each Auger Torque drive ensures that the output shaft is locked in place and will NEVER fall out of the gearbox housing.

We offer a lifetime guarantee against the shaft falling
out of your auger drive.

Gearbox Design

Auger Torque manufactures their own planetary gearbox. The unique design features the non-dislodgement shaft design, and maximizes the final output torque of the unit at the operating hydraulic pressure. Manufacturing their own gearbox allows Auger Torque to maintain high quality and reliability that you depend on for your attachments.

Warranty Information

We provide replacement warranty units for the coverage listed below.

All Auger Torque products are warranted for the periods below:

Planetary Gearbox Components – 72 Months
Hydraulic Motors – 36 Months
All Other Parts / Products – 24 Months

For any additional information on the Auger Torque range, you can visit their website here!

Tools that also suit these auger drives:

Frequently Asked Question’s

Is there anything else I need to go to work?

No, this package includes everything that you need in order to get to work. Hydraulic drive, excavator mount, stump auger bit as well as hoses & couplers.

What is needed to build a mount for my excavator?

We require a spec form with the measurements from your machine in order to build a mount that fits properly. This is pin diameters, pin center measurement and stick width.

Does this auger drive with 2″ hex shaft?

Yes, the 2" hex output shaft is the most popular in the US market.

Can I use the 14″ planer on my excavator?

If your excavator is in the weight range to suit the 3300-30, we recommend that you use the 10″ diameter planer. The 14″ will stall out in the stump and struggle to spin. For the 14″ we recommend the model 6000-40 on a larger machine.

Are the blades and tip replaceable?

Yes the blades and pilot tip are both replaceable.

What are the blades made from?

The blades are made from heat treated carbide.

Excavator Stump Planer Package Deal – Excavators up to 10 tons (22,000lbs)

Share On Social Media

The Ultimate Excavator Stump Planer Auger Package Deal for machines up to 10 tons!

Specifications

Model 3300-30 (up to 6 tons or 30GPM)

Model 6000-40 (up to 10 tons or 40GPM)

Auger Drive Features

Warranty Information

Tools that also suit these auger drives:

Frequently Asked Question’s

If you can’t find the answer to your question or Quote Request, contact us below!
